Product description

Stainless steel corrugated hose is a kind of industrial metal material which can be flexible and has good temperature and pressure resistance. According to the use classification: mainly includes metal bellows, corrugated expansion joints, corrugated heat exchanger pipe, diaphragm diaphragm box and so on. Metal bellows for the thin-walled stainless steel welded pipe for wave processing and become rich in flexibility and good temperature and pressure resistance. Applicable to air, steam, various industrial gases and water, oil, pharmaceuticals and other types of fluid media transport, the Reciprocating motion of the pipe system, thermal expansion system to absorb, vibration absorption, and piping center adjustment play an important role.

Material	201 stainless steel or 304 stainless steel
Length	30m/50m
Color	silver
Product size	F1/2*F1/2
Product name	corrugated hose
package	Paper box/Woven bag
Type	Flexible Water Hose
Product application	Hot and cold water inlet-outlet pipe of water heater/faucet/shower/toilet and other equipment

Corrugated stainless steel hose for cold and hot drinking water supply, fire extinguishing, heating, electrical wiring, and gas supply. It is produced with a wall thickness of 0.25-0.3 mm, and made of high-alloyed food-grade AISI304 stainless steel. Available in lengths 20，30，50 meters/Roll.

Advantages

● Good flexibility performance:

Stainless steel bellows roll is designed with metal hose, which has fast bending and deformation ability. When bending, it can effectively absorb vertical displacement, axial displacement, angular displacement, etc. This flexibility makes it an ideal choice when connecting pipes and equipment.

● Excellent corrosion resistance:

The main body is usually made of 304 or 316L stainless steel, both of which have excellent corrosion resistance and can adapt to various corrosive media. This corrosion resistance is especially important in petroleum, chemical, and other industries, ensuring the long-term stable operation of the piping system.

● Reliability under high temperature and high pressure:

It can withstand high temperature and high-pressure environments with high reliability. Its actual working pressure has been carefully calculated and repeatedly tested to ensure the safety of pressure in a variety of harsh working conditions.

● Good seismic performance:

It can effectively reduce the aging and maintenance costs of the piping system. This seismic performance is especially important in earthquake-prone areas or occasions where dynamic loads need to be borne.

●Small size and lightweight:

It is easier to install and maintain than traditional cast iron and steel pipes. This not only reduces the difficulty of construction but also reduces the cost of materials and time.

● Multiple specifications and customized services:

A wide range of diameters, generally DN5-DN4000, can also be customized according to customer requirements. This flexibility allows it to meet the needs of various piping systems.

● Beautiful appearance:

The appearance is clear and bright, permanently bright as new, not only practical but also decorative.

Application

Petroleum and chemical industries: It is widely used in petroleum transport, oil and gas mixtures, and the transmission of various chemicals and corrosive media. Its corrosion resistance, high-temperature resistance, and flexibility make it ideal for use in these industries.

Construction industry: It is used in underground drainage pipes, natural gas pipelines and so on. Its good sealing properties and vibration resistance make it a preferred material in the construction sector.

Food and Pharmaceutical Industry: Due to the high cleanliness and hygiene requirements for food hygiene and pharmaceutical production, stainless steel bellows play an important role in conveying a variety of food and pharmaceutical products. Its stainless steel material complies with hygienic standards and ensures product quality and safety.

Automotive industry: It is mainly used in automotive exhaust systems, which can effectively reduce noise and vibration and improve the exhaust efficiency of the engine. In addition, it can also be used in the air intake system and cooling system of automobiles.
