Brushed Gold Concealed ThermostaticLuxury Rain Mixer Shower Set

Concealed shower sets are installations where the water supply pipe for the bathroom shower is pre-buried inside the bathroom wall in advance. This type of installation needs to be planned ahead of time during the renovation process, burying the water supply pipe inside the wall and exposing only the shower head and switch,  to achieve a simple and beautiful effect.   A concealed shower is a more discreet type of installation. During installation, the main part of the showerhead is mounted inside the wall, exposing only the spout. This method of installation requires an excavation in the wall to house the shower and its connecting pipes. Concealed showerheads have a beautiful, clean appearance, blending in with the overall décor for a more unified visual effect. As it is hidden inside the wall, it also avoids surface wear and aging problems caused by prolonged use.

Name	Shower set
Application	Bathroom/Hotel
Surface Treatment	Brushed Nickel, Brushed Gold, Matte Black,Brushed Gray, Chrome
Body Material	Brass Cu≥59%, Cr 0.25μm, Ni 8μm
Cartridge	Ceramic cartridge, 500,000 cycles testing
Number of Handles	Single handle
Hot-Cold Water	Yes
Water flow	Basin Faucet 1.2GPM, Kitchen Faucet 1.8GPM, Shower Head 1.8GPM (Can be customized according to customer requirements)
Hoses	1.5m（59"),Diameter 0.18mm, thickened 304 stainless steel wire precision compilation, ultra-strong corrosion resistance, resistance to 3.5Mpa high pressure without bursting
100% Testing	24h acid salt spray test, pressure system test; 200 hours neutral salt spray test
Customer Service	Free for Laser Customized Logo on the faucet or Shower set and Identification Label on the box.
Technical Support	1. Installation instruction manual in the box for free. 2. Online install instruction. 3. Graphic Design.
OEM & ODM	Support
Sampling Time	10-15 days
Delivery Time	20ft container is 30-45 days, 40ft container is 45-60 days
Warranty	5 Years

1. Space saving

Concealed shower is a design that conceals the shower area between the wall and the floor, which can make full use of space and will not take up a lot of indoor space. Compared with traditional shower stalls, the concealed shower is more suitable for small households, which perfectly solves the problem of space bottleneck.

2. Aesthetics

Concealed shower design makes the shower space more beautiful and fashionable because it can be completely integrated with the environment so that the whole bathroom space is simpler and generous. At the same time, picking the right showerhead, faucet, floor tiles, and other decorations can also better enhance the high-end sense of comfort of the entire shower space.

3. More Private

Concealed shower can better protect the user's privacy compared with the traditional shower area. Because the shower area is concealed between the wall and the floor, there is no need to worry about moisture in the air and the odor of the wrapping agent leaking outside the bathroom.

4. Easy to clean

Since a concealed shower is a cleaner shower design, it is easier to clean. All that is needed is to clean the shower water instead of having to clean the entire shower each time.

1. Wall grooving:

According to the parameters of the plumbing direction and the height of the shower set, use the slotting aid to draw the specific slotting position on the wall. Perform slotting on the wall, the recommended slotting dimensions for the body of the pre-embedded box are 10 cm long, 20 cm wide, and 4 cm deep (specific dimensions may vary from product to product, refer to the product manual).

2. Clean the foreign matter in the groove: After opening the groove, carefully clean the gravel, dust, and other foreign matter in the groove to ensure that the groove is smooth and neat.

3. Hot melt connection of water pipe: connect the PP-R water supply pipe with the main body of the concealed shower valve by hot melt connection. Observe the level meter above the main body and adjust the horizontal position to ensure that the upper surface of the socket is flush with the wall, so as to facilitate the installation of accessories such as panels in the later stage.

3. Water pressure test: use the external teeth plug to block the outlet, water pressure test to ensure that the connection is not leaking. The main body of the concealed pre-installed box is made of PP-R material, which is connected to the PP-R pipeline by hot fusion, and should enjoy the same pressure test service as the pipeline.

4. Mud and sand backfill: mud and sand backfill at the trenching place, pay attention to the cement that can't cover the main body, to avoid the protective cover can't be dismantled.

5. Tiling: When tiling, pay attention to the size of the tile opening, generally recommended to be 8 cm wide and 17 cm high (specific size should be determined according to the product manual).

6. Do not remove the protective cover before installing the bathroom components to avoid damage to the spool during construction. There is a “tile paste range” indicator line on the protective cover, please make sure that the later tiling surface is within this range.

7. Installation of fittings: After the completion of the tiling, install the top spray, hand shower, panel, handle, and other accessories. Ensure that all fittings are firmly installed and not loose.
